31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS

    Buy cheap 31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS from wholesalers

    Buy cheap 31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS from wholesalers
    • Buy cheap 31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS from wholesalers
    • Buy cheap 31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS from wholesalers
    • Buy cheap 31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS from wholesalers

    31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS

    Ask Lasest Price
    Brand Name : Visench
    Model Number : 31-20KL
    Supply Ability : 10000pcs/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS

    High Frequency Online UPS

    XT Series (single phase)


    PRODUCT FEATURES


    1. Advanced CPU digital control technology

    2. Active input power factor correction (PFC)

    3. Frequency adaptive system

    4. Ultra wide input voltage range

    5. Output power factor is 0.9

    6. Ultra wide input frequency range

    7. Strong scalability

    8. Green and environmental protection


    PARAMETER 1-3KVA
    ModelX1KVA1KS2KVA2KS3KVA3KS
    Rated Power 1kVA/0.9kW2kVA/1.8kW3kVA/2.7kW
    InputVoltage Range90-285Vac 1P2W+G
    Working Frequency Range40-70Hz (settable)
    Input Power Factor≥0.99
    OutputRated Voltage and Accuracy220Vac(1±2%) 1P2W+G
    Output Frequency46-54Hz synchronize with mains power; 50Hz (Mains power between 40-46Hz and 54-60Hz ); 50Hz(Battery)
    Rated Current4.5A9.1A13.6A
    Output Power Factor0.9
    Output Harmonic Wave≤4% (Full R load)
    Crest Factor  3:1
    Output OverloadOverload pre-warning :100%±2%<Load Output warning:102%±2%≤Load≤110%±2%: Convert to bypass mode and alarm after 30mins;
    Output warning:110%±2%<Load≤130%±2%: Convert to bypass mode and alarm after 10mins;
    Output warning:130%±2%<Load≤150%±2%: Convert to bypass mode and alarm after 30s; Convert to bypass mode and alarm after 200ms, Load>150%±2%
    Conversion time between Mains Power and Battery0ms
    Efficiency≥90% (Normal mode)
    BatteryRated Voltage24Vdc36Vdc48Vdc72Vdc72Vdc96Vdc
    Quantity2External4External6External
    Charging Current1A5.5A1A5.5A1A5.5A
    Dimension (LxWxH) mm280x144x230400x144x230425x190x328400x144x230
    Weight7.8kg4.2kg13.3kg6.4kg23.4kg6.5kg
    Working Temperature0℃-40℃
    Working Humidity20%-95% (non-condensing)
    Noise≤50dB


    31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS31-20KL Parallel Operation Three Phase High Frequency Rack Mount UPS Pure Sine Backup Battery Power Supply Online UPS
