    3 Phase Galaxy VX UPS 500kVA 500kW 400V For Large Data Center

    Ask Lasest Price
    Brand Name : APC
    Model Number : GVX500K500NHS
    Certification : CE EAC RCM
    Payment Terms : L/C, D/A, D/P, T/T
    • Product Details
    • Company Profile

    3 Phase Galaxy VX UPS 500kVA 500kW 400V For Large Data Center

    Features

    500 to 1500kW N+1
    The Schneider Electric Galaxy VX UPS is a scalable, high-performance extension of the Galaxy V-Series solutions, designed for large data center and industrial applications:
    • Lower your energy costs and meet changing business requirements, with 99% efficiency in ECOnversion mode.
    • Provide excellent power quality in demanding electrical environments.
    • Install and deploy your UPS quickly.
    • Manage your power anywhere. Galaxy VX supports local and remote communication via touchscreen, Web interface, Modbus, and the Schneider Electric StruxureWare for Data Center Expert solution.

    Benefits

    Availability
    • Parallel-capacity capable - Increases total power capacity by using multiple uninterruptible power supplies simultaneously.
    • Compatible with Schneider Electric's lithium ion battery solution - Reduces system footprint and weight, cooling and maintenance requirements, and total cost of ownership; offers double the life of VRLA batteries; and improves backup storage predictability and manageability.
      Click here for more details.
    • Internal backfeed protection - Increases system defense from power anomalies.
    • Energy storage flexibility - Conventional flooded and modular battery offer along with different charging modes allows tailoring to specific back-up requirements.
    • Parallel-redundant capable - Power the connected equipment with multiple uninterruptible power supplies to increase system redundancy
    Serviceability
    • StruxureOn enabled - Simplify maintenance and operation of your equipment through the use of vendor-neutral, cloud-based software and services.
    • Multiple levels of service - With the option of packages or individual service components, our services are structured to allow you to pick and choose what you would like APC to do for you.
    • StruxureWare Data Center Expert compatible - Enables centralized management via StruxureWare Data Center Expert.
    • Front-access servicing - Simplifies installation and UPS maintenance while minimizing space requirements.
    • 5x8 Start-up service included - Required for full coverage of factory warranty
    Total cost of Ownership
    • Wide input voltage range - Designed for harsh electrical environments to save battery life.
    • ECOnversion mode - Operating mode that ensures ultra high efficiency while charging the batteries, conditioning the load power factor and ensuring a Class 1 output voltage regulation.
    • Input Power Factor Correction - Minimizes installation costs by enabling the use of smaller generators and cabling.
    • ECO Mode - Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
    • Robust operation - No power derating in kW up to 40 degrees C or 104 degrees F.

    Specifications

    Overview
    PresentationA highly efficient, modular, 500 kVA 3-phase UPS that provides the performance, flexibility, and maximized asset utilization today’s large data centers and mission critical applications require. This EcoStruxure connected UPS features up to 99% efficiency in eConversion mode. Includes 5x8 start-up service.
    Lead timeSpecial Order - Call for Quoted Lead Times

    Main
    Main Input Voltage400 V 3 phases
    Other Input Voltage380 V
    415 V
    440 V
    Main Output Voltage400 V 3 phases
    Other Output Voltage380 V
    415 V
    440 V
    Rated power in W500 kW
    Rated power in VA500 kVA
    Battery typeExternal battery system
    Provided equipmentInstallation guide
    Start-up service

    Batteries & Runtime
    EfficiencyView Efficiency Graph
    action_new_window
    Battery voltage480 V
    Discharge battery voltage384 V DC
    Battery power in VAH0 VAh runtime
    Extended runtime0

    General
    RedundantNo

    Physical
    ColourWhite
    height197 cm
    Width240 cm
    Depth90 cm
    Net weight2030 kg
    USB compatibleNo

    Input
    Network frequency40...70 Hz
    Maximum input current851 A
    Max short time withstand current100 kA
    Input harmonic distortionLess than 3 % for full load
    Load power factorFrom 0.7 leading to 0.5 lagging without any derating

    Output
    Maximum configurable power in W500 kW
    Output frequency50 Hz sync to mains
    60 Hz sync to mains
    50 Hz +/- 0.1 % for 50 Hz nominal unsynchronised
    Crest factor3 with THC <5%
    Wave typeSine wave
    Output harmonic distortion< 2% linear load and < 3% non-linear load
    Output overload operation10 minutes at 125% and 60 seconds at 150%
    Maximum configurable power in VA500 kVA

    Conformance
    product certificationscUL listed
    C-Tick
    CE
    UL 1778 5th edition
    StandardsIBC 2012
    IEC 62040-1-1
    IEC 62040-2
    IEC 62040-3
    IEC 62040-4
    ISTA 2B

    Environmental
    ambient air temperature for operation0…40 °C
    Relative humidity0…95 % non-condensing
    Operating altitude0...3333 ft
    Ambient air temperature for storage-15…40 °C
    Storage Relative Humidity0…95 % non-condensing
    Storage altitude0.00…15240.00 m
    Acoustic level69.5 dBA
    heat dissipation80387 Btu/h
    IP degree of protectionIP20

    Communications & Management
    Free slots2
    control panel7" touch screen display

    Packing Units
    Unit Type of Package 1PCE
    Number of Units in Package 11
    Package 1 Height215 cm
    Package 1 Width106 cm
    Package 1 Length317 cm
    Package 1 Weight2592 kg

    Contractual warranty
    Warranty1 year on-site repair or replace with factory authorized Start-Up
