    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS

    Ask Lasest Price
    Brand Name : Visench
    Model Number : Visench Giant Elite
    Price : $867.00 - $1,008.00/pieces
    • Product Details
    • Company Profile

    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS

    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    Product name
    Giant Elite 3p1p
    Rated Capacity
    6kva-10kva
    Voltage Regulation
    ± 1%
    Input Voltage
    3x360VAC1380VAC1400VAC(3Ph+N+G)
    Frequency
    40 Hz~ 55 Hz @ 50Hz system ; 56 Hz~ 64 Hz @ 60Hz system
    Output Voltage
    208VAC1220VAC/230VAC (Se lectable)
    Waveform
    Pure Sinewave
    Battery Type
    12V/ 9Ah
    PHASE
    3-phase in / 1-phase out
    Harmonic Distortion
    ≤ 3 % THD (Linear Load); ≤ 5 % THD (Non-inear Load)
    Current Crest Ratio
    3:01
    Battery Mode
    92.00%
    Frequency Range
    50 Hz ± 0.1 Hz or 60Hz± 0.1 HZ
    Inverter to Bypass
    Zero
    Operating Temperature
    0 ~ 50°C
    Size(mm)
    592x300x826
    Weight(Kgs)
    129/137/152/160/168
    MODEL
    Giant Elite 31-6K(L)
    Giant Elite 31-7.5K(L)
    Giant Elite 31-10K(L)
    PHASE
    3-phase in /1-phase out
    CAPACITY*
    6KVA/4.8KW
    7.5KVA/6KW
    10KVA/8KW
    INPUT
    Nominal Voltage
    3x360VAC/380VAC/400VAC(3Ph+N+G)
    Voltage Range
    286VAC~493VAC @16 pcs of batteries;320VAC~493VAC @18 pcs of batteries
    Freguency
    40 Hz~55 Hz@50Hz system;58 Hz~84 Hz @6OHz system
    OUTPUT
    Output Voltage
    208VAC/220VAC/230VAC(Selectable)
    Voltage Regulation
    ±1%
    Frequency Range (Synchronized Range)
    45Hz~55 Hz or 56 Hz~64 Hz
    Frequency Range (Batt.Mode)
    50Hz±0.1 Hz or 60Hz±0.1 Hz
    Curent Crest Ratio
    3:1
    Hamonic Distortion
    ≤3%THD(Linear Load);≤5%THD (Non-linear Load)
    Transfer Time
    AC to DC
    Zero
    Inverter to Bypass
    Zero
    Waveform(Batt.Mode)
    Pure Sinewave
    EFFICIENCY
    AC Mode
    83%
    Battery Mode
    92%
    BATTERY
    Standard Model
    Battery Type
    12V /9Ah
    Battery Numbers*
    16 pcs
    Recharging Time
    6 hours recover to 90% capacity
    Charging Current (max.)
    2A
    Charging Voltage
    218.4V±1%
    Long-run Model
    Battery Type
    Depending on the applications
    Numbers
    16 pcs
    18 pcs
    16 pcs
    18 pcs
    16 pcs
    18 pcs
    Changing Current (max.)
    Default:8A;2A/4A/BA(Adjustable)
    Charging Voltage
    218.4V±1%
    245.7V±1%
    218.4V±1%
    245.7V±1%
    218.4V±1%
    245.7V±1%
    INDICATORS
    LCD
    UPS status,load level,battery level,inputloutput voltage and frequency,fault code/waming code
    ALARM
    Battery Mode
    Sounding every 4 seconds
    Low Battery
    Sounding every second
    Overload
    Sounding twice every second
    Fault
    Continously sounding
    PHYSICAL
    Standard Model
    Dimensions,DxWxH (mm)
    502x300x826
    592x380x826
    592x300x826
    592x360x828
    592x300x826
    592x360x826
    Net Weight (Kgs)
    129
    137
    152
    160
    160
    168
    Long-run Model
    Dimensions,DxWxH (mm)
    592x300x828
    Net Weight (Kgs)
    84
    107
    115
    ENVIRONMENT
    Operating Temperature
    0~50°℃(battery life cycle will be shorten when temperature is above 25°℃)
    Operating Humidity
    <95% and non-condensing
    Noise Level
    Less than 80dBA @1 Meter
    MANAGEMENT
    Smart RS-232/USB
    Supports Windows 2000/2003/XPNista/2008/7/8/10,Linux,Unix,and MAC
    Optional SNMP
    Power management from SNMP manager and web browser
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    COMPANY PROFILE:
    Vesion Tech Co., Ltd. is located in Futong Haizhi Technology Park, Shenzhen, with a 1,500 m² R&D center and sales center base. Also,our business partner have an automated production plant of 10,000 m² in Foshan, Guangdong.
    We are a high-tech company focusing on one-stop data centers, PV new energy, and smart power supply and distribution. We provide users with infrastructure products such as UPS system, HVAC, MDC, smart power supplies, and PV new energy.
    As a technical facilities provider, Vesion also cooperates with well-known brands such as Eaton, Vertiv, Santak, APC, etc. to provide customers with the best choice.
    Vesion follows the national carbon neutrality strategy and based on the development concept of independent innovation, constantly pursues leadership in energy-saving technology and innovation in production processes, and has established a complete R&D and quality assurance system. Provide customers with data center infrastructure and photovoltaic new energy solutions.

    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    208VAC/220VAC/230VAC Visench Giant Elite 6000W 7500W 10000W 3Phase Industrial Tower UPS
    1. May I take some samples to test before I placing the order?
    Yes, we can offer sample testing for you to verify product quality and performance.

    2. What is the warranty?
    We support 1 years warranty.

    3.What can you buy from us?
    Eaton, Vertiv, APC, Santak, Vesion & OEM/ODM UPS; Cooling, MDC, PDU and so on.

    4. What payment methods does your conmpany support?
    We could accept T/T, credit card, Alipay or L/C at sight.

    5. What are the terms can you offer for us?
    We could offer EXW, FOB, CIF, DDP and so on.
